The only 1 kW 8-pin transom mount transducer, it has a depth of 1,800 to 2,500 ft; an operating frequency of 50 to 200 kHz; a beamwidth of 19 to 6 degrees; and mounts on a 2 to 20 degree transom.
Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.
When using with a 6-pin Garmin sounder, transducer adapter cable part number 010-11612-00 is required.
Unit dimensions, WxHxL: 31/32" x 43/64" x 3 3/32" (24.7 x 17.0 x 78.6 mm)
Total cable length: 16 ft. (4.9 m)
Temperature range: From 5°F to 158°F (from -15°C to 70°C)
Compass Safe Distance: 2 in. (5 cm)
Power Input Source: 9–16 Vdc from the NMEA 2000 bus
NMEA 2000 Power Usage: 1.1 W max
NMEA 2000 Load Equivalency Number (LEN): 2 (100 mA)
