Image Sensor Device: 1/3 in. (8.5 mm) Sony Super HAD CCD camera
Effective Pixels: 768 x 494 (NTSC), 752 x 582 (PAL)
Scanning System: 2:1 Interlaced, 525 lines (NTSC), 625 lines (PAL)
Sync System: Internal
Resolution: 480 TV lines
Video Output: VBS, 1.0V peak-to-peak, composite, 75 ohms
S/N Ratio: More than 48 dB (AGC off)
Operating Temperature: From -20C to 60C
Power Consumption: 80mA at 12Vdc (with LED on, 120 mA, maximum)
Weight: 11.3 oz. (320g)
Dimensions: Diameter, 2 3/8 in.: height, 2 1/4 in. (diameter, 60 mm: height, 57 mm)
Compass Safe Distance: 6 1/8 in. (155 mm)
Waterproof rating: IP66
